Heavy Machinery Epoxy Grout Systems
Vibration-Resistant Grouting for Compressors, Turbines, Pumps & More
Heavy Machinery Epoxy Grout
When it comes to anchoring high-load, high-vibration equipment, precision matters.
ZDSpoxy’s Heavy Machinery Epoxy Grout Systems are engineered to provide unmatched load transfer, compressive strength, and zero-shrink durability, helping industrial plants, energy facilities, and OEMs ensure long-term stability and alignment.
- No middlemen
- Fast prototyping
- Private label available
Why Heavy Equipment Grouting Fails
Many failures stem from low-strength cement grout, poor flow, or cracking from heat. These issues lead to:
- Loosening anchor bolts
- Equipment misalignment or tilt
- Vibration amplification
- Grout delamination or voids
- Costly shutdowns and maintenance
📌 Grout isn’t just filler—it’s a load-bearing foundation system.
ZDSpoxy epoxy grout is your insurance against equipment movement, failure, and downtime.
Application Scenarios
ZDSpoxy epoxy grout systems are trusted for:
| Application | Grout Function |
| Compressor foundations | High-strength + flow into deep pockets |
| Turbine baseplates | Zero-shrinkage + heat resistance |
| CNC & forging equipment bases | Dynamic load transfer + vibration damping |
| Crushers, grinders, rotary kilns | Chemical-resistant + impact-tolerant |
| Anchor bolts, sole plates, rails | Gap-filling + anchoring precision |
Recommended Grout Systems
ZDSpoxy offers multiple epoxy grout models tailored for machinery installation:
| Model ID | Key Feature | Use Case Highlight |
| ZDS1410AB | Ultra high compressive strength (>100 MPa) | Heavy compressors, CNCs, baseplates |
| ZDS4130AB | Flowable, low exotherm | Thick pours, large equipment pads |
| ZDS4120AB | Heat-resistant formula (up to 160°C) | Turbines, engines, gearboxes |
| ZDS3382AB | Low viscosity for tight gaps | Narrow soleplates, anchor bolts, retrofit jobs |
- Download TDS & SDS for All Models
- Request a Quote Based on Your Project
Key Benefits of ZDSpoxy Epoxy Grout for Machinery
>100 MPa Strength
Superior load transfer
Zero Shrinkage
Prevents movement or gaps
Long Pot Life
Up to 60 min workable time
Chemical & Oil Resistance
Suitable for industrial floors
Flowable
Fills under baseplates, including tight and uneven areas
Cures in Harsh Conditions
Low-temp & high-heat variants available
Typical Failure Scenarios – and Fixes
| Symptom | Likely Cause | ZDSpoxy Solution |
| Cracking under baseplate | High exotherm + poor curing | Use ZDS4130AB (low exotherm) |
| Voids around anchor bolts | Poor flow or improper formwork | Use ZDS3382AB + headbox technique |
| Shrinkage pulling from edges | Wrong grout type | Switch to 0-shrink ZDS1410AB |
| Pump or turbine vibration | Soft grout or poor bond | Upgrade to ZDS4120AB (heat + strength) |
Installation Notes (For Project Engineers)
Surface Prep
Substrate must be roughened and oil-free
Formwork
Use headbox or funnel-pour setup for baseplate gaps
Mixing
Slow-speed mixer, avoid whipping air
Pouring
Maintain one-direction flow, avoid cold joints
Curing
Protect from vibration/movement for 24–48h
Inspection
Tap test or ultrasound to check voids
Need to grout a machine base, anchor a soleplate, or secure high-vibration equipment?
ZDSpoxy epoxy grout systems are trusted by contractors, energy plants, OEMs, and engineering firms worldwide.
